232to485
RS232-RS485 Model:MX-232T485-01-V1.0 Core parameter
Key Specs
| Size | 4.7(L)*2(W)*1(H) cm |
|---|
Full Specification
RS232-RS485
Model:MX-232T485-01-V1.0
Core parameter
Item | Introduction | |
Power | power input，GND | 5~12V |
Communication interface | RS232 | 1 set |
RS485 | 1 set | |
Communication mode | Two-way communication | |
Size | 4.7(L)*2(W)*1(H) cm | |
Wire length | RS232 | 19.5 cm |
RS485 | 19.5 cm | |
Wire harness | power input | red，Casing text：12V/5V |
GND | black，Casing text：GND | |
RS232 RX | white，Casing text：RX | |
RS232 TX | yellow，Casing text：TX | |
RS485A | yellow，Casing text：RS485A | |
RS485B | white，Casing text：RS485B | |
